cnc router CXM2030-A2
No.1 Features1. The machine body is strong, rigid, high precision, reliable and durable. 2. Imported high-precision square rail linear gap, smooth movement, to ensure that the machine tools high-preci
Send inquiry
No.1 Features
1. The machine body is strong, rigid, high precision, reliable and durable.
2. Imported high-precision square rail linear gap, smooth movement, to ensure that the machine tools high-precision.
3. Using well-known domestic brands of water-cooled spindle, low noise, strong cutting ability, to ensure the long time working.
4. Good three-axis structure to ensure that the machines longer service life.
5. High-performance driven motor to ensure that the machines high speed and accurancy
6. Designer perfectly, select the best machine accessories, to minimize the failure rate preferred
7. Breakpoint specific memory, power outages continued carving, processing time forecast, and otherfunctions to ensure that accidental processing
8. Compatility, compatible Type3/ Artcam/ Ucacam and so on a variety of CAD/CAM design software.
No.2 Application
1. Mould: wood,wax, wood, gypsum,foams,wax
2. Furniture: wooden doors, cabinets, plate, office and wood furniture, tables, chair, doors and windows.
3. The wood products: voice box, game cabinets, computer tables, sewing machines table,instruments.
4. Plate processing: insulation part, plastic chemical components, PCB, inner body of car, bowling tracks, stairs, anti bate board, epoxy resin, ABS, PP, PE and other carbon mixed compounds.
5. Decorate industry: Acrylic, PVC, MDF, artificial stone, organic glass, plastic and soft metals such as copper engraving and milling process.
| No.3 Parameters | ||
| Model | CXM2030-A2 | |
| Driver and Inverter | leadshine driver and fuling inverter | |
| X Y Z Traveling Area | 2000mm*3000mm*200mm | |
| Table Structure | Aluminum T-Slot or Vacuum | |
| Spindle Power | 3.0KW Water Cooling | |
| Ball screw | Taiwan TBI | |
| Max. Spindle Speed | 24000r/min | |
| Max. Traveling Speed | 12000mm/min | |
| Max. Working Speed | 8000mm/min | |
| Processing Accuracy | ±0.025mm | |
| Reposition Accuracy | ≤0.025mm | |
| Driving System | Stepper Motor or Servo Motor | |
| Operation System | Mach 3(optional DSP/NC-STUDIO) | |
| Software | Type3, Artcam, Ucancam | |
| Working Voltage | AC 220/380V | |
| Net Weight/Gross Weight | 1500 KG/ 1800KG | |
| Tool Sensor | Yes | |
| Filter | Yes | |
| No.4 Porfessional service | ||
| 1. 2 years warranty for the whole machine. We will change the machine part for free if it is broke because of quality problems, except consumable parts. 2. Lifetime maintenance free of charge. 3. Free training course at our plant. 4. 18 hours on line service and email each day, free technical support. 5. Machine has been adjusted before delivery.We will take machine photos and make machine working image for you ,after getting your agreement ,then we will book a ship. 6. Provide technical services to the door (We have professional engineers to offer machine installation commissioning and maintenance) if customers pay the charges of ticket. 7. If you have any problem during your use.you need our technician to judge where the problem is and help you to solve it. We can provide team viewer and skype with cam till all of your problems solved. Training: 1. We will supply with the machine operation manual in English version. 2. For installation and operation, including introduction for the composing of equipment, working principle of equipment, common knowledge of computer, controlling principle of electric devices,daily maintenance measures of equipment. 3. User can dispatch representatives to our factory for 1-2days training. We are responsible for training them free of charge. | ||
No.5 Related models: CXM1325, CXM1530, CXM2030, CXM2040, CXM2060 etc
