mixed cut laser machine CXJ1530-H-2
No.1 FeaturesCXJ1530-H-2 is a mixing cutting machine, widely used in metal and nonmetal cutting and engraving. lead shine stepper motor to ensure the high precision, running stable and long-operation
Send inquiry
No.1 Features
CXJ1530-H-2 is a mixing cutting machine, widely used in metal and nonmetal cutting and engraving. lead shine stepper motor to ensure the high precision, running stable and long-operation.
2. Special follow up laser cutting head, which can sense a distance from the nozzle to the metal surface and follow the surface up and down to automatically adjust the certain focus distance for keeping high precision.
3. RDCAD/CAM Laser Work control system with English Color screen display and compatible with USB, PC and various memeries.
4. HIWIN square rail with high precision and stable of cutting.
5. Famous brand RECI laser tube with long life ( more than 10000 hours).
6. The weight of the cutting machine is about 1.2tons, much heavier than others, to reduce the precision error caused by machine vibration.
7. Low running cost which is about 5KVA/hour.
No.2 Application
Nonmetal industries: acrylic products, logo signs, electronics, furniture, toys, flooring, advertising display, gifts, models, industrial panel. Metal cutting industry: sheet metal structure, high and low voltage electrical cabinet making, hardware, tools, advertising signs, metal crafts, decorating, automotive, petrochemical, medical, mechanical parts, electrical meter parts, saw blades, spring-chip and other industries.Metal materials: stainless steel, carbon steel, alloy steel, spring steel and other metal plates;
Non-metallic materials: acrylic, wood, plastic panels.
No.3 Technical parameters
| model | CXJ1325-H-2 |
| Working area | 1300mm x 2500mm |
| Laser Types | Seal CO2 Laser Tube |
| Laser power | 150W (Optional:180W /220W /260W /300W) |
| Engraving speed | 100-600mm/s |
| Cutting speed | 0-30mm/s |
| Location precision | ≤0.01mm |
| Resetting positioning accuracy | 0.01mm |
| Power supply | AC110- 220V/50-60HZ |
| Controlling software | Ruida 6332M |
| Operating temperature | 0 - 45° |
| Operating humidity | 5-95% |
| Minimum shaping character | English 1 x 1mm |
| 360°slope engrave | Yes |
| Driving system | Leashine |
| Cooling mode | Water-cooling and protection system |
| Auxiliary Devices | Exhauster and the Exhaust Pipe |
| Software | RDCAM V6.0 |
| Graphic format supported | BMP, CIF, JPEG, TGA, TIFF, PLT, AI, DXF, DWG,etc |
| Min. Shaping character | English 1.0x1.0mm |
| Option | Red dot pointer positio, working table,rotary,auto-focusing |
No.4 After-sales service
--Warranty: 24 months for laser machine; 10 months for laser tube
--Technical support for the whole lifetime of laser machine
--If there is any part broken during warranty, then change it for free. if out of warranty, you can buy the part at your market easily as we use very famous brand and we tell you the model, or you can buy it from us and cost price can be promised
No.5 Related models :CXJ9060-H-2 /1290-H-2 /1390-H-2 /1490-H-2 /1610-H-2 /1325-H-2 /1525-H-2 etc
