auto-feeding laser cutting machine
No.1 Auto Feeding co2 laser cutting machine Feature 1.Autofeeding system, apply netted platform with special design, very convenient for free movement of processing pieces.2. Big size to meet large fo
Send inquiry
No.1 Auto Feeding co2 laser cutting machine Feature
1.Autofeeding system, apply netted platform with special design, very convenient for free movement of processing pieces.
2. Big size to meet large format cutting.
3. Control system with USB interface.
4.machine is the double-head auto feeding laser cutting machine which is independently researched and improved by bodor, it is one high speed and scientific auto feeding device . After improvement, it achieves, it achieves to keep on working and collecting material automatically, and make sure the integrity of material at same time.
5. with electric laser head that can move freely, you could adjust distance between two heads according your needs. It is no need to move by hand any more .Each head can finish whole format processing work independently.
No.2 Application
Cutting, engraving and punching soft materials, such as all sorts of clothing, leather, carpet, suede fabric, denim jeans, stuffed toys, textiles, industrial fabrics etc.
No.3 Configurations parameter of auto feeding co2 laser cutting machine
| Name: | fabric auto feeding laser cutting machine1626 |
| Processing area | 1600mm*2600mm |
| Laser power | 80w ,100W,130W,150W |
| Laser type: | Sealed CO2 glass laser tube |
| Cooling mode: | Water cooling and protection system |
| Resetting positioning accuracy: | ±0.01mm |
| Compatible Software: | Laser cut 5.3, CorelDraw AutoCAD Photoshop |
| Whole machine size: | 1600*2600mm |
| Engraving speed | 1-6000mm/min |
| Cutting speed | 1-1000mm/min |
| Cutting thickness | 0-15mm acrylic (others determined by materials) |
| Resolution ratio | ≤0.0125mm |
| Position system: | Red dot |
| Interface: | USB |
| Minimum shaping character | letter 0.8mm, Chinese 2mm |
| Support graphic format | DST, PLT, BMP, DXF |
| Cooling mode: | Circulation water cooling |
| Working voltage: | AC 110 - 220V±10%, 50 - 60Hz or depend on customer |
| Operating temperature | 0-45C |
| Operating humidity: | 5-95% |
| Driving system | stepper |
| Packing: | wooden box |
| Guarantee time: | 2 years |
| Option: | Rotary attachment for column materials |
| Operation: | Video to tell customer how to operate the machine |
No.4 Service
1. Guarantee for 2 years (10 months for laser tube) exluding comsumable parts. Extra fee is paid if out of date. Any damage to the machine caused by improper use will be charged.
2. Free training course at our plant.
3. We will provide the consumable parts at an agency price when you need replacement.
4. 16 hours on line service each day, free technical support.
5. Machine has been adjusted before delivery, operation disk was included. If there is also any questions, pls kindly tell me.
7. We have manual instruction and CD (Guiding Videos) for Software's Installing and operation and Machine's Using and Maintaining.
No.5 Related models CXJ1610, CXJ1325, CXJ 1525, CXJ1530 etc
