stone laser engraving machine CXJS1390
No.1 Feature of the stone laser machine 1.up-down worktable which is suitable for thick materials2.engraving objects with greatly thickness changing is much easier to process3.Separable machine body,
Send inquiry
No.1 Feature of the stone laser machine
| 1. | up-down worktable which is suitable for thick materials |
| 2. | engraving objects with greatly thickness changing is much easier to process |
| 3. | Separable machine body, can move onto the materials which facility heavy material process |
| 4. | Reliable engraving effect(equalize the diminishing of the light to ensure the same engraving and cutting effect in different areas) |
| 5. | Advanced DSP control system |
| 6. | Leetro 6585 control card |
| 7. | Marble, granite, all kinds of stones can be engraved with high precision and fast speed |
| 8. | Also can engrave on wood, leather, glass, fabric, paper, PVC, ABS, beans, ceramic and other non-metal materials |
No.2 The laser machine application
| 1.Marble, granite, all kinds of stones can be engraved with high precision and fast speed |
| 2.wood, leather, glass, fabric, paper, PVC, ABS, beans, ceramic and other non-metal materials |
No.3 Parameter
| Name: | CXJ1S390 |
| Processing area | 1300mm*900mm (2feet*1.3feet) |
| Laser power | 90W |
| Laser type: | Sealed Co2 glass laser tube |
| Cooling mode: | Water cooling and protection system |
| Resetting positioning accuracy: | ±0.01mm |
| Compatible Software: | Laser cut 5.3, CorelDraw AutoCAD Photoshop |
| Whole machine size: | 1890*1330*1070MM |
| Engraving speed | 1-60000mm/min |
| Cutting speed | 1-10000mm/min |
| Cutting thickness | 0-15mm acrylic (others determined by materials) |
| Resolution ratio | ≤0.0125mm |
| Position system: | Red dot |
| Interface: | USB |
| Minimum shaping character | letter 0.8mm, Chinese 2mm |
| Support graphic format | DST, PLT, BMP, DXF |
| Gross power | 1000W |
| Driving mode: | DC0.8A 24V stepper motor |
| Cooling mode: | Circulation water cooling |
| Working voltage: | AC 110 - 220V±10%, 50 - 60Hz or depend on customer |
| Operating temperature | 0-45degree |
| Operating humidity: | 5-95% |
| Driving system | stepper |
| Option: | Up and down table, rotary attachment |
| Packing: | Strong plywood |
| Guarantee time: | 1 year, laser tube 8 months |
| Option: | Rotary attachment for column materials |
| Operation: | Video to tell customer how to operate the machine |
| Net weight: | 300KGS before package, 350KGS after package |
No.4 After-sale service
1. 2y ears quality guaranty, the machine with main parts(excluding the consumables) shall be changed free of charge when if there is any problem during the warranty period.
2. Lifetime maintenance free of charge.
3. Free training course at our plant.
4. We will provide the consumable parts at an agency price when you need replacement.
5 .24 hours on line service each day, free technical support.
6. Machine has been adjusted before delivery , operation disk was included.
No.5 Related models :CXJ9060/1290/1390/1490/1610/1325/1525 etc
