laser machine 1325
No.1 Features1. High-strength stable machine, weighing about two tons, long-term work is not deformed, not distorted, the appearance of bright, paint the strength of corrosion resistance, easy to rust
Send inquiry
No.1 Features
1. High-strength stable machine, weighing about two tons, long-term work is not deformed, not distorted, the appearance of bright, paint the strength of corrosion resistance, easy to rust, easy maintenance.
2. No burr/fraying with laser cutting:It can make cut edge to close up automatically. Hence, no need to recut the patterns after one-time cutting.
3. Singapore imported lenses to make the laser light spot smaller, have a stronger cutting capacity, greatly improving the efficiency and reduce the cost of materials;
4. Forced water cooling protection, automatic temperature control, to ensure that the laser tube for a long time continuous work.
5. Beijing Reci laser tube, using life more than 8000-10000 hours.
6. Can be directly on the operate panel to modify the processing parameters of each layer (such as: speed, power, etc.).
7. The RD system is the latest generation, has better hardware stability and better anti-high voltage and anti-static interference.
8. Design software of CAD,CORELDRAW, are all supported for friendly human-computer interface and demand of the industries on-the-spot.
No.2 Application
1.Applicable materials: wood, bamboo, organic glass, crystal, plastic, garments, paper, leather, rubber, ceramic, glass and other nonmetal materials.
2.Applicable industries: advertisement, gift, shoes, toys, computers, garments, model cutting, building, packaging, paper industry.
No.3 Parameters
| Laser power | W2(90-100W) Beijing Reci laser tube, Other laser power tube is optional |
| laser type | water cooling |
| power supply | AC220V ±10% 50HZ/AC110V ±10% 60HZ |
| working area | 1300*2500mm |
| max moving speed | 0-40000mm/min |
| worktable | honey comb worktable, aluminium knife (optional, up/down worktable,) |
| location precision | <0><!--0--> |
| Min shaping Character | character:2×2mm,letter:1×1mm |
| Operating Temperature | 5°C-35°C |
| Resolution Ratio | ≤4500dpi |
| Control Configuration | Ruida controller, Leetro 6595 controller |
| Data Transfer interface | USB (offline) |
| System Environment | windows2000/windows XP/ Vista/win7/win8 |
| Cooling Way | water cooling and protection system |
| Graphic Format Supported | TheFileswhichCorelDraw.Photoshop. AutoCADCanidentify(BMP,GIF,JPGE, |
| PCX,TGA,TIFF,PLT,CDR,DMG,DXF,PAT,CDT,CLK,DEX,CSL,CMX,AI,WPG,WMF, | letter 0.5mm, Chinese 0.5mm |
| EMF,CGM,SVG,SVGZ,PCT,FMV,GEM,CMX) | DST, PLT, BMP, DXF |
| Compatible Software | CorelDraw, AutoCAD |
| Cutting Thickness | 0-20mm(depends on different materials) |
| Color Separation | separation of cutting up to 256 colors |
| Sloping Engraving | Yes, slope can be designed discretionarily |
| Cuts off the Water Supply the Protection | yes |
| Machine Dimension | 3750*2020*1280mm |
| Package Dimension | 3770*2030*1310mm |
No.4 SERVICE
(1) Pre-sale services:
* Provide the free consultation of the equipment .
* Provide the standard device and the flow chart.
* According to the clients’ special requirement, offering the reasonable plan and free design helping to select the equipment.
* Welcome to visit our factory.
(2)Services during the sales:
* Inspect the machine before leaving the factory.
* Oversea install and debug the equipment
* Train the first-line operator.
(3)After sale services:
* 24 hours online service.
* Provide the VIDEO with Install and debug the equipment.
* Provide technical exchanging.
Service In Life-Time: No matter how many years passed, you always can contact me, we can give you any technical support in the future life-time.
No.5 Related models :CXJ9060/1290/1390/1490/1610/1325/1525 etc
