desktop fiber laser marking machine with protective cover
No.1 Machine featuresa. Various laser generator can be choosed Optical fiber laser integrated structure, no optical pollution, no power of the coupling loss, compact structure compact, air cooling. Ra
Send inquiry
No.1 Machine features
a. Various laser generator can be choosed Optical fiber laser integrated structure, no optical pollution, no power of the coupling loss, compact structure compact, air cooling. Rayucs/CAS/MAX/IPG/MOPA.
b. Original EZCAD software
The computer with original EZCAD software will be shipped togther with the machine.
EZCAD software is a special imagining software which support all-English, Chinese, Japanese and Korean.
c. Excellent beam quality
The optical fiber laser is the medium mixed yb double-clad fiber, resonant cavity length.
Beam quality is very good, M2 value is 1.2-1.5, the output flare diameter can achieve 10 microns.
No.2 Application
a. Application materials
What are the detailed materials applied for optical fiber laser marking machine ?
Many type of metals: Gold,Silver,Stainless Steel,Copper,Aluminum,chrome Brass,etc Alloy and metal oxides: Anodized Aluminum
Some non-metallic materials & Special surface treatment:silicon wafer,ceramics,plastic, rubber,epoxy resin,ABS,Printing ink, Plating, Spraying, Coating film.
b. Application industry
What are the applicable industries for optical fiber laser marking machine ?
Electrical Engineering and Electrical part and component Mobile (Cover,battery,keyboard, I Phone Case) Jewellery(Ring,pedeant,bracelet),eyeglass,clocks and craft
Building materials, PVC pipe
Car motor car spare part
Insturment and meters and cutting tool
plastic case
hardware fitting and accessory
sanitary appliance
food and beverage
Medicine package and medical instrument
solar Photoelectrical PV industry
No.3 Technical parameter
| Product name | Fiber laser marking machine CXF-20W |
| Laser source | Raycus/CAS/MAX/IPG/MOPA |
| Laser source | 20W/30W/50W |
| Control system | PC control system |
| Image software | EZCAD software |
| Laser wavelength | 1064nm±10nm |
| Minimum line width | 0.01mm |
| Minimum character | 0.1mm |
| Marking speed | 10000mm/s |
| Marking depth | 0~1mm |
| Engraving line speed | ≤3000mm/s |
| Beam quality | M2:1.2~1.8 |
| Working voltage | 220V±10%/50Hz/4A |
| Laser module life | >100000hours |
No.4 Shipping ways
⇒Deliver by sea
(1) Please kindly tell me your nearest port
(2) Please kindly tell me your detailed address
⇒Deliver by air
(1) Please kindly tell me your nesrest airport.
(2) Please kindly tell me your detailed address and post code.
⇒Deliver by land
(1) Please kindly tell me your city.
(2) Please kindly tell me your detailed address
No.5 Related models CXF-20W, CXF-30W, CXF-50W etc
