portable cnc plasma cutting machine 1325
No.1 Features1. With very high precision for cutting SS MS and other metals.2. Any plasma source can work with the machine well3. Small cutting gap, with no residua4. Light design of the beam promises
Send inquiry
No.1 Features
1. With very high precision for cutting SS MS and other metals.
2. Any plasma source can work with the machine well
3. Small cutting gap, with no residua
4. Light design of the beam promises high cutting speed and accuracy
5. Working with computer and support G code and files of WENTAI, type 3 software
Keywords of the portable cnc flame cutting machine
portable cnc flame cutting machine , small portable flame cutting machine , flame cutting machine ,plasma cutting
machine ,plasma cutter , flame cutter , flame cutting machine price , metal cutting machine ,plasma cutting machine price,
flame cutting machine for sale
No.2 Application
This machine can cut mild steel with flame cutting, and cut high carbon steel, stainless steel,aluminum, copper and other non-ferrous metal with Plasma cutting; can configurate as you required.,thus it is widely applied in industries such as machinery, automobile, shipbuilding, petro-chemical, war industry, metallurgy, aerospace, boiler and pressure vessel, locomotive etc.
Suitable for sheet processing, do word, etc., and other advertising equipment (vacuum molding machine, engraving machine, slotting machine, etc.,) the formation of advertising word processing line. Dozens of times higher than that of traditional craft rocessing efficiency.
No.3 Parameter
Cutting Technical Data | ||||
Model | CXP | |||
Effective Cutting area (mm) | 1200x1500 | 1500x3000 | 1500x4000 | 1500x6000 |
Cutting Thickness(mm) | Flame:40-200mm , Plasma:1-40mm | |||
Cutting Speed (mm/min) | 50-3800 | |||
Running speed (mm/min) | 12000 | |||
Basic components | ||||
Cutting Mode | Plasma or Flame or plasma and flame dual use | |||
Drive Motor Number | Servo motor or stepper motor , Dual-side | |||
Cutting Torch Number | Customize according user's need | |||
Driving Motor | China stepper | |||
Controller | Starfire | |||
Plasma Power | Any brand | |||
Programming software | Auto CAD | |||
Nesting software | China or Australia professional nesting software | |||
Gearbox | Neugart planet | |||
Other Data | ||||
Working temperature | - 10°C -45°C | |||
Humidity | <90><!--90--> | |||
Surroundings | Ventilation, no big shake | |||
Power voltage | 3×380V±10% or up by user’s local condition | |||
Operation language | English or Chinese or Russian | |||
No. 4 Guarantee & after sale service
Guarantee for 24 months,18-hour technical support by email or calling User-friendly English manual and Video CD for machine using and maintaining.
No.5 Related models: CXP1530, LXP1540, LXP1550, LXP1560 etc.
